Aluminum Bus Bars 6101 T65 T61 Customize
6101 aluminum bus bar is a conductive aluminum component designed for electrical and power distribution systems. It offers high electrical conductivity (up to 57% IACS) while maintaining a lightweight structure and lower cost than copper, making it a practical and efficient alternative for many power applications.
Advantages of 6101 Aluminum Bus Bar
Electrical Conductivity
Typically: 55–60% IACS
Ideal for efficient current transfer in electrical systems
Mechanical Properties
Good balance of strength and ductility
Suitable for bending and fabrication
Burs bar aluminum 6101 Specifications and Sizes
Thickness: 2--20mm and Customizable
Width: 30--130mm and Customizable
Length: 3/6/12m or cut-to-size
Temper:T61, T63, T64 T65
Shape: Right angle, Rounded corner, R angle(no burs on edge)
Surface treatment: Powder coating, anodizing, electroplating(tin plating, silver plating,nickel plating)
Standards & Certifications:ASTM B317, IEC 60105
Applications of 6101 Aluminum Bus Bar
Our products are widely used in:
Power distribution systems
Switchgear and control panels
Transformers
Renewable energy (solar & energy storage)
Electric vehicles (EV systems)
Industrial electrical installations
6101 Aluminum vs Copper Bus Bar
| Property | 6101 Aluminum | Copper |
|---|---|---|
| Conductivity | Moderate (55–60% IACS) | High |
| Weight | Lightweight | Heavy |
| Cost | Lower | Higher |
| Corrosion Resistance | Good | Good |
6101 aluminum is a cost-effective and lightweight alternative for many electrical applications where copper is not strictly required.
Why Choose Our 6101 Aluminum Bus Bars?
Strict quality inspection: dimension meansurement, bending test, conductivity test, resistance test.
Standard export packaging (wooden cases / pallets)
Moisture-proof protection
Flexible shipping terms: FOB, CIF, EXW
Reliable global logistics support
