Marine grade Aluminum Plate 5083 H111 H116 H321
What is Marine grade Aluminum Plate 5083 H111 H116 H321?
Marine Grade Aluminum Plate 5083 (H111, H116, H321) is a lightweight, high-strength material renowned for its exceptional corrosion resistance and durability in marine and coastal environments. This aluminum alloy is widely used for constructing ship hulls, decks, and superstructures, as well as in transportation, storage tanks, and architectural projects in high-humidity areas. Its ability to withstand harsh weather and seawater exposure, combined with excellent formability and weldability, makes it a reliable choice for demanding applications.
Shenzhen Chinalcometal limited has such stock materials : Marine grade Aluminium Plate AA 5083 H111 / H112 / H116 / H321) with DNV / ABS / BV / Lloyd's Class Cert.
5083-H111 aluminum plate is 5083 aluminum in the H111 temper. To achieve this temper, the metal is strain hardened to a strength that is lower than what is permissible for H11 (1/8-hard).
Chemical Composition of Aluminum alloy 5083
Chemical Composition | |||||||||
% | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Al |
Min | 0.4 | 4 | 0.05 | ||||||
Max | 0.4 | 0.4 | 0.1 | 1 | 4.9 | 0.25 | 0.25 | 0.15 | Remainder |
Stock list of Marine grade Aluminum Plate 5083 H111 H116 H321
Tempers: H111 ,H116,H321
Specifications: DNV / ABS / BV / Lloyd's Class Cert
Alloy | Temper | Thickness | Size(mm) |
5083 | H111 | 1 | 1250-2000x2500-8000 |
5083 | H111 | 1.5 | 1250-2000x2500-8000 |
5083 | H111 | 2 | 1250-2000x2500-8000 |
5083 | H111 | 2.5 | 1250-2000x2500-8000 |
5083 | H111 | 3 | 1250-2000x2500-8000 |
5083 | H111 | 4 | 1250-2000x2500-8000 |
5083 | H111 | 5 | 1250-2000x2500-8000 |
5083 | H111 | 6 | 1250-2000x2500-8000 |
5083 | H111 | 8 | 1250-2000x2500-8000 |
5083 | H111 | 10 | 1250-2000x2500-8000 |
5083 | H111 | 12 | 1250-2000x2500-8000 |
5083 | H111 | 15 | 1250-2000x2500-8000 |
5083 | H111 | 16 | 1250-2000x2500-8000 |
5083 | H111 | 18 | 1250-2000x2500-8000 |
5083 | H111 | 20 | 1250-2000x2500-8000 |
5083 | H111 | 25 | 1250-2000x2500-8000 |
5083 | H111 | 30 | 1250-2000x2500-8000 |
5083 | H111 | 35 | 1250-2000x2500-8000 |
5083 | H111 | 40 | 1250-2000x2500-8000 |
5083 | H111 | 45 | 1250-2000x2500-8000 |
5083 | H111 | 50 | 1250-2000x2500-8000 |
5083 | H111 | 55 | 1250-2000x2500-8000 |
5083 | H111 | 60 | 1250-2000x2500-8000 |
5083 | H111 | 65 | 1250-2000x2500-8000 |
5083 | H111 | 70 | 1250-2000x2500-8000 |
5083 | H111 | 75 | 1250-2000x2500-8000 |
5083 | H111 | 80 | 1250-2000x2500-8000 |
5083 | H111 | 85 | 1250-2000x2500-8000 |
5083 | H111 | 90 | 1250-2000x2500-8000 |
5083 | H111 | 95 | 1250-2000x2500-8000 |
5083 | H111 | 100 | 1250-2000x2500-8000 |
5083 | H111 | 110 | 1250-2000x2500-8000 |
5083 | H111 | 120 | 1250-2000x2500-8000 |
5083 | H111 | 130 | 1250-2000x2500-8000 |
5083 | H111 | 140 | 1250-2000x2500-8000 |
5083 | H111 | 150 | 1250-2000x2500-8000 |
5083 | H111 | 160 | 1250-2000x2500-8000 |
5083 | H111 | 170 | 1250-2000x2500-8000 |
5083 | H111 | 180 | 1250-2000x2500-8000 |
5083 | H111 | 190 | 1250-2000x2500-8000 |
5083 | H111 | 200 | 1250-2000x2500-8000 |
5083 | H111 | 250 | 1250-2000x2500-8000 |
5083 | H111 | 290 | 1250-2000x2500-8000 |
5083 | H111 | 300 | 1250-2000x2500-8000 |
