AMS4911 Titanium Ti-6Al-4V Grade 5 Sheet Plate
AMS4911 Ti-6AL-4V (Grade 5) Titanium Sheet and Plate, specified under AMS 4911, is a high-strength, lightweight titanium alloy commonly used in aerospace, medical, and high-performance engineering applications. This alloy is composed of 6% aluminum, 4% vanadium, and the balance titanium, providing an excellent balance of strength, corrosion resistance, and weldability.
Size of AMS4911 Titanium Ti-6Al-4V Grade 5 plate sheet
Titanium Grade | AMS4911 Titanium Ti-6Al-4V Grade 5 plate sheet | ||
Thickness | 0.5mm--120mm; | ||
Width | 1000mm --4000mm | ||
Length | 1000mm--6000mm | ||
Mechanical properties | Tensile strength/MPa | Yield strength at 0.2% offset /MPa | Elongation in 4D %l.t. |
0.5mm- 8mm | 899 | 828 | 10 |
8mm-60mm | 896 | 827 | 10 |
60mm-120mm | 896 | 827 | 10 |
Composition of AMS4911 Titanium Ti-6Al-4V Grade 5 plate sheet
Element | % |
Aluminum | 5.5-6.75 |
Vanadium | 3.5-4.5 |
Iron | 0.3 |
Oxygen | 0.2 |
Carbon | 0.08 |
Nitrogen | 0.05 |
Hydrogen | 0.0125 |
Yttrium | 0.005 |
Other elements each | 0.1 |
Other elements total | 0.4 |
Tinanium | Balance |
